Week 6-7: Egg Eater, Due Friday, May 15

In this assignment you'll implement heap allocated structures in your compiler.

Setup

There is a mostly empty starter repository for this assignment -- the same starting code as diamondback, so you can start by adding your code from diamondback to it. Functions are necessary, but you can get away with 1- and 2-argument functions, so you can start from code from class.

Your Additions

You should add the following features:

<expr>
  ::= ...
    | nil
    | (vec <expr> <expr> <expr> ... <expr>)
    | (vec-get <expr> <expr>)

1. A nil construct, that is a special constant that can represent an empty vector; nil should be considered distinct from all other vectors, so (= nil (vec ...)) should evaluate to false. For simplicity, you might as well make other comparisons like (= nil 3), (= nil true), (= nil false), also evaluate to false, but we will not test this;

2. An extension (vec ...) for heap-allocation of an arbitrary non-zero number of values. This is a generalization of the (vec <expr> <expr>) from class. (The mechanism from class by itself is not be sufficient because it only supports two-element vectors). The easiest thing might be to add tuples with any number of positions in the constructor (e.g. (vec <expr>+));

3. An expression for lookup that allows computed indexed access. That is, in (vec-get <expr> <expr>) the first expression evaluates to a vec and the second evaluates to a number, and the value at that index is returned. This expression must report a dynamic error if an out-of-bounds index is given, or if either the first expression is not a vec OR the second expression is not a number; in either case your error message should contain "invalid".

4. If a heap-allocated value is the result of a program or printed by print, all of its contents should be printed in some format that makes it clear which values are part of the same heap data. For example, in the output all the values associated with a particular location may be printed as (vec ...) as in the sample tests (see below);

5. You should be able to detect when out-of-memory occurs; your language should be able to allocate at least a few thousands of words, but if it runs out of space, it should exit with a message "out of heap space".

6. Any other features needed to express the programs listed in the section on required tests below (we will not require implementing vec-len and vec-set but of course, you are most welcome, or even encouraged to do so.)

7. As before the input value will, as before only be a number or boolean.

The following features are explicitly optional and not required:

• Updating elements of heap-allocated values
• Structural equality (= can mean physical/reference equality)

Required Tests

We have given some of the below tests, but you should also at least add more, e.g. bst.snek.

• input/simple_examples.snek – A program with a number of simple examples of constructing and accessing heap-allocated data in your language.
• input/error-tag.snek – A program with a runtime tag-checking error related to heap-allocated values.
• input/error-bounds.snek – A program with a runtime error related to out-of-bounds indexing of heap-allocated values.
• input/error3.snek – A third program that tests that your compiled code is able to detect when you are out of heap space, and exits with that message.
• input/points.snek – A program with a function that takes an x and a y coordinate and produces a structure with those values, and a function that takes two points and returns a new point with their x and y coordinates added together, along with several tests that print example output from calling these functions.
• input/bst.snek – A program that illustrates how your language enables the creation of binary search trees, and implements functions to add an element and check if an element is in the tree. Include several tests that print example output from calling these functions.

Happy hacking!
